▲Stepper motor subdivided drive, DC power supply, high precision, stable operation.
▲The switch value controls the start-stop and forward and reverse directions.
▲Beautiful appearance, small size, simple and intuitive operation, suitable for OEM supporting use.
| Internal control speed range | 5-100rpm, step-by-step adjustment (see Table 2 for details) | Applicable power supply | 11.4-25.2V DC; or 100-240V AC (optional power adapter) 50/60Hz |
| External control speed range | 0-100rpm, speed resolution 0.1rpm, linear correspondence throughout the whole process | Power consumption | ≤12W |
| Speed error | ≤±1rpm | working environment | Ambient temperature: 0-40℃, relative humidity: <80% |
| Start-stop control | Switch control: the contact is normally open, the peristaltic pump is running; the contact is closed (port 5 and port 7 are short-connected), the peristaltic pump stops | Dimensions | (Length × width × height) 106 × 60 × 92 (mm) |
| Direction control | Switch control: the contact is normally open, the peristaltic pump runs clockwise; the contact is normally closed (port 6 and port 7 are shorted), the peristaltic pump runs counterclockwise | weight |
425g |
| TS100-A&WX10 peristaltic pump flow parameters | |||||
| Drive model | Number of pump head rollers | Number of channels | Applicable hose | range of rotation | Maximum reference flow |
| （ml/min） | |||||
| TS100-A&WX10-14 | 4 | 1 | 1*1 | 0.1-100 | 0.0045-4.44 |
| 2*1 | 0.02-19.71 | ||||
| 3*1 | 0.039-38.92 | ||||
| TS100-A&WX10-18 | 8 | 1 | 1*1 | 0.1-100 | 0.0033-3.2 |
| 2*1 | 0.013-12.65 | ||||
| 3*1 | 0.023-21.41 | ||||
